- Product introduction
- Parameters
- Effect Video
|
PRINT CONTROL SYSYTEM |
|
|
Model Printheads |
GC2000TX Epson i3200 or Espon4720 |
|
Print speed |
6-8EPSON 320 ©O/h 260 ©O/h |
|
Print Resolution |
300¡Á600£»600¡Á600£»1200¡Á1200 dpi |
|
Ink |
Dye Sublimation ¡¢Water Base ink |
|
Colors |
C.M.Y.K.O.B.FY.FR |
|
Ink supply method |
Automatic degassing, automatic negative pressure system |
|
Printhead maintain |
Automatic cleaning Automatic moisturizing |
|
Rip software |
Photoprint £¬NeoStampa |
|
|
|
|
Media system |
Volume to volume |
|
Print width Material width |
2000mm 2050mm |
|
Material |
Heat transfer paper |
|
Coil specifications |
The maximum diameter of 1200mm |
|
HEATING SYSTEM |
|
|
Weight capacity |
800kg |
|
Heating system |
PID constant temperature control |
|
DIMENSIONS (L x W x H) |
|
|
Printer size |
3720x1400x1730mm |
|
Package Size |
3900x1600x1900cm |
|
PRINTER WEIGHT |
|
|
Weight |
650kg |
|
OPERATING CONDITIONS |
|
|
Temperature |
25 - 28¡ãC |
|
Relative humidity |
50% - 65% |
|
ELECTRICITY REQUEST |
|
|
Power supply |
Hosts£ºAC220V¡À10% 50/60HZ¡¢10A Dryer£ºAC220V¡À10% 50/60HZ¡¢16A |
|
Pressure |
0.6Mpa£¨ Dry gas£© |
|
|
|
|
warranty period |
One year (please consult your local dealer for details) |
